Model: ZXC48 SE
Engine
Type: Kohler Command PRO®
Engine Gross hp (kW): 22.5 (16.77)
Displacement cu. in. (cc): 42.35 (694)
Choke: Manual
Fuel Tank Capacity gal. (l ): 12.5 (47.31)
Fuel Requirement: Unleaded Gasoline (87 Octane or higher)
Drive Train
Model: Hydro-Gear ZT-3400
Displacement (Pump/Motor) cc: 12/16
PTO Type
Clutch ft./lb.: 200
Electrical
Charging System amp: 15
Tire Size
Front: 13 x 6.5-6
Rear: 23 x 10.5-12
Traveling Speeds
Forward mph (km/h): 10 (16.1)
Parking Brake: Internal Integrated in Axle
Dimensions
Overall Length in. (mm): 80.7 (2,049.78)
Overall Width in. (mm): 60.7 (1,541.78)
Overall Height in. (mm): 71.5 (1,816.1)
Wheelbase in. (mm): 48.5 (1,231.9)
Width (Tire to Tire) in. (mm): 51.3 (1,303.02)
Approximate Curb Weight lb. (kg): 939 (425.92)
Mower Deck
Mower Deck Type: Fabricated
Lift Mechanism: Foot Pedal
Deck Steel Thickness: 10-gauge with 7-gauge at edge area
Anti-Scalp Ball Rollers: 5 (4 front, 1 rear)
Cutting Width of Mower in. (mm): 48 (1,219.2)
Blades: Notched (Opt. Serrated)
Cutting Height in. (mm): 1.5-5 (38.1-127)
Discharge Chute: Side (Molded Rubber)
Deck Height Adjustment: Dial Type
Seat
Suspension: Standard (3 Inch Suspension with High Back)
Sliding Adjustment: Standard
Arm Rest: Standard
Seat Belt: Standard
Standard/Optional
Foldable ROPS: Standard
Head Light: Standard
Power Socket: Standard
Model: ZXC54 SE
Engine
Type: Kohler Command PRO®
Engine Gross hp (kW): 23.5 (17.52)
Displacement cu. in. (cc): 42.35 (694)
Choke: Manual
Fuel Tank Capacity gal. (l ): 12.5 (47.31)
Fuel Requirement: Unleaded Gasoline (87 Octane or higher)
Drive Train
Model: Hydro-Gear ZT-3400
Displacement (Pump/Motor) cc: 12/16
PTO Type
Clutch ft./lb.: 200
Electrical
Charging System amp: 15
Tire Size
Front: 13 x 6.5-6
Rear: 23×10.5-12
Traveling Speeds
Forward mph (km/h): 10 (16.1)
Parking Brake: Internal Integrated in Axle
Dimensions
Overall Length in. (mm): 80.7 (2,049.78)
Overall Width in. (mm): 67.3 (1,709.42)
Overall Height in. (mm): 71.5 (1,816.1)
Wheelbase in. (mm): 48.5 (1,231.9)
Width (Tire to Tire) in. (mm): 51.3 (1,303.02)
Approximate Curb Weight lb. (kg): 957 (434.08)
Mower Deck
Mower Deck Type: Fabricated
Lift Mechanism: Foot Pedal
Deck Steel Thickness: 10-gauge with 7-gauge at edge area
Anti-Scalp Ball Rollers: 6 (4 front, 2 rear)
Cutting Width of Mower in. (mm): 54 (1,371.6)
Blades: Notched (Opt. Serrated)
Cutting Height in. (mm): 1.5-5 (38.1-127)
Discharge Chute: Side (Molded Rubber)
Deck Height Adjustment: Dial Type
Seat
Suspension: Standard (3 Inch Suspension with High Back)
Sliding Adjustment: Standard
Arm Rest: Standard
Seat Belt: Standard
Standard/Optional
Foldable ROPS: Standard
Head Light: Standard
Power Socket: Standard
Model: ZXC60 SE
Engine
Type: Kohler Command PRO®
Engine Gross hp (kW): 25 (18.64)
Displacement cu. in. (cc): 45.58 (747)
Choke: Manual
Fuel Tank Capacity gal. (l ): 12.5 (47.31)
Fuel Requirement: Unleaded Gasoline (87 Octane or higher)
Drive Train
Model: Hydro-Gear ZT-3400
Displacement (Pump/Motor) cc: 12/16
PTO Type
Clutch ft./lb.: 200
Electrical
Charging System amp: 15
Tire Size
Front: 13 x 6.5-6
Rear: 23 x 10.5-12
Traveling Speeds
Forward mph (km/h): 10 (16.1)
Parking Brake: Internal Integrated in Axle
Dimensions
Overall Length in. (mm): 81.7 (2,075.18)
Overall Width in. (mm): 72.6 (1,844.04)
Overall Height in. (mm): 71.5 (1,816.1)
Wheelbase in. (mm): 49.5 (1,257.3)
Width (Tire to Tire) in. (mm): 51.3 (1,303.02)
Approximate Curb Weight lb. (kg): 992 (449.96)
Mower Deck
Mower Deck Type: Fabricated
Lift Mechanism: Foot Pedal
Deck Steel Thickness: 10-gauge with 7-gauge at edge area
Anti-Scalp Ball Rollers: 8 (4 front, 4 rear)
Cutting Width of Mower in. (mm): 60 (1,524)
Blades: Notched (Opt. Serrated)
Cutting Height in. (mm): 1.5-5 (38.1-127)
Discharge Chute: Side (Molded Rubber)
Deck Height Adjustment: Dial Type
Seat
Suspension: Standard (3 Inch Suspension with High Back)
Sliding Adjustment: Standard
Arm Rest: Standard
Seat Belt: Standard
Standard/Optional
Foldable ROPS: Standard
Head Light: Standard
Power Socket: Standard
