Engine Model: 3HT-S4TM45A
Weight with Ag Tires: 4,027 lbs. / 4,614 lbs.
Control Type: Position with Draft Control
Lift Capacity, 24 in. aft of hitch, lb (kg): 2,493 lbs.
Standard Category: Category # 1 & 2
Pump Capacity (Max. Flow Rate): 16.5 gpm
Pump: Gear
Turning Radius with Brake: 11.04 ft. / 11.16 ft.
Ground Clearance: 13.4 in.
Wheelbase: 75.5 in.
Height from Top of ROPS / Cab: 98.4 in. / 93.7 in.
Width: 67.1 in.
Length with 3-point hitch: 136.4 in.
Clutch: Dry Single Plate
Brakes: Wet Multi Disc
Mid PTO Speeds: 2000 (optional)
Rear PTO Speeds (1st): 540
PTO Power: 36.6 hp
PTO Type Trans: Independent
Max. Travel Speed of Forward with Ag1 @ Engine rated speed: 16.7 mph (forward) & 14.8 mph (reverse)
Min. Travel Speed of Forward with Ag1 @ Engine rated speed: 0 mph (forward) & 0 mph (reverse)
Engine Gross Power: 44.9 hp
Rated Speed: 2600 rpm
No. of Cylinders: 3
Fuel Type: Diesel
Aspiration: Turbo Charged
Displacement: 111.4 cu. in.
Fuel Tank Capacity: 13.2 gal.
Transmission Type: Manual: Synchro Shuttle
Shuttle: Synchronized
No. of Travel Speeds – Forward / Reverse: 12 / 12 (3 Ranges)
