Engine Model: 3C100LFU-U2
Engine Type: 4-Cycle Diesel, 3 Cyl., In-line Vertical, Water-Cooled
Engine Gross: 24 hp (17.89 kW)
Displacement: 61.45 cu. in. (1,007 cc)
Rated Revolution: 3,000 rpm
Fuel Tank Capacity: 9.7 gal. (37 ℓ)
Drive Train
Type: Belt CVT
Gear Range: Low, High, Neutral, Reverse
Ground Speed: 0-31 mph (0-50 km/h)
Brake: Front/Rear Hydraulic Disc
Suspension
Front Suspension: Independent, Double A-Arm (Wishbone Type)
Rear Suspension: Independent, Double A-Arm (Wishbone Type)
Steering
Type: Hydraulic Power
Dimensions
Length: 149.2 in. (3,790 mm)
Width: 62.5 in. (1,590 mm)
Height: 76.9 in. (1,955 mm)
Wheelbase: 112.2 in. (2,850 mm)
Ground Clearance: 12 in. (304 mm)
Max Front Wheel Tread: 49.7 in. (1,262 mm)
Max Rear Wheel Tread: 49.8 in. (1,264 mm)
Turning Radius: 18.4 ft. (5.6 m)
Weight: 2,314.8 lbs. (1,050 kg)
Towing Capacity: 1,300 lbs. (590 kg)
Payload Capacity: 1,750.5 lbs. (725 kg)
Cargo Bed
Length x Width x Depth: 39.2 x 58.2 x 11.5 in. (1,010 x 1,480 x 293 mm)
Bed Capacity: 661.5 lbs. (300 kg)
