Engine Model: 3F1863T-55
Height from Top of ROPS Folded: N/A
From Top of the Highest Point: N/A
Wheelbase: 71.3 in. (1,810 mm)
Ground Clearance: 15.2 in. (387 mm)
Front Tread Ag Tires – Min: 49.4 in (1,254 mm)
Front Tread Ag Tires – Max: N/A
Rear Tread Ag Tires – Min: 49.3 in (1,251 mm)
Rear Tread Ag Tires – Max: N/A
Turning Radius with Brake: 8.6 in (2.6 mm)
Turning Radius without Brake: N/A
Total Pump Flow: Pump Type
Main Pump Capacity: 14.5 gpm (55.1 lpm)
Power Steering Pump Capacity: N/A
3-Point Hitch Standard Category (Optional Category): Category II
Lift Capacity, 24″ aft of hitch, lb(kg): 2,716 lbs. (1,232 kg)
Control Type: Position
Weight with Ag Tires with ROPS: 3373 lbs. (1530 kg)
Weight with Ag Tires with Cab: N/A
Height from Top of Cab: N/A
Height from Top of ROPS: 92 in. (2,338 mm)
Width: 62.8 in. (1,596 mm)
Length with 3-point hitch: 124.8 in. (3,170 mm)
Clutch: Dry Single Plate
Brakes: Wet Multi Disc
Front PTO Speeds: N/A
Rear PTO Speeds(2nd): N/A
Mid PTO Speeds: N/A
Rear PTO Speeds(1st): 540 rpm
PTO Power: 49.6 HP (37 KW)
PTO Type Trans: Independent
Max. Travel Speed of Forward with Ag1 @ Engine rated speed: 17.3 mph (27.9 kph)
Min. Travel Speed of Forward with Ag1 @ Engine rated speed: 1.35 mph (2.17 kph)
No. of Travel Speed Forward / Reverse: 8 x 8
Main Gear: N/A
Shuttle: Manual
Transmission Type: Synchronized
Pre-heating System: Glow Plugs
Fuel Tank Capacity: 11.9 US Gal (45 l)
Engine Gross Power: 55 HP (41.0 KW)
Rated Speed: 2,600 rpm
No. of Cylinder: 3
Fuel Type: Diesel
Aspiration: Turbo Charged
Displacement: 111.4 cu.in. (1,826 cc)
Kioti – DK5520
CRDI Diesel Engine with Daedong ECO Technology
The new Common Rail Diesel Engine (CRDI) improves fuel efficiency while reducing noise levels. With this eco-friendly Tier 4 engine, the DK series offers the operator a quiet work environment with powerful performance.
Projection and Working Lamp
With the new projection head and working lamp, the operator will experience safer and easier operation after the sun goes down.
Additional information
| Additional Features | Deluxe Suspension Seat Fender Grip Large capacity hydraulic pump PTO Cruise Tail Lamp High Ground Clearance Center Marker Power and Tilt Steering |
|---|
