Model: RC1048
Product Description: Low Horsepower 48″ Single-Spindle Cutter
Tractor PTO Range (hp): 15-50
Hitch Category / Type: Category 1 / Cantilevered
Cutting Width (in.): 48
Cutting Height Range (in.): 2-9
Cutting Capacity (in.): 1
Gearbox (hp): 50
Blade Tip Speed (fpm): 13100
Deck Side Depth (in.): 7
Approximate Weight (lb.): 410
Blade Dimensions (in.): .5 x .3
Blade Carrier: Oval Stump Jumper
Tail Wheel: 4 x 16 Laminated
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3/8 Rails
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Cutting Area Shielding: Belt Standard/Chain Shielding Optional
Warranty (cutter/gearbox): 1 Year/3 Years

Model: RC1060
Product Description: Low Horsepower 60″ Single-Spindle Cutter
Tractor PTO Range (hp): 18-50
Hitch Category / Type: Category 1 / Cantilevered
Cutting Width (in.): 60
Cutting Height Range (in.): 2-9
Cutting Capacity (in.): 1
Gearbox (hp): 50
Blade Tip Speed (fpm): 13620
Deck Side Depth (in.): 7
Approximate Weight (lb.): 494
Blade Dimensions (in.): .5 x .3
Blade Carrier: Oval Stump Jumper
Tail Wheel: 4 x 16 Laminated
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3/8 Rails
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Cutting Area Shielding: Belt Standard/Chain Shielding Optional
Warranty (cutter/gearbox): 1 Year/3 Years

Model: RC1072
Product Description: Low Horsepower 72″ Single-Spindle Cutter
Tractor PTO Range (hp): 21-50
Hitch Category / Type: Category 1 / Cantilevered
Cutting Width (in.): 72
Cutting Height Range (in.): 2-9
Cutting Capacity (in.): 1
Gearbox (hp): 50
Blade Tip Speed (fpm): 14340
Deck Side Depth (in.): 7
Approximate Weight (lb.): 575
Blade Dimensions (in.): .5 x .3
Blade Carrier: Oval Stump Jumper
Tail Wheel: 4 x 16 Laminated
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3/8 Rails
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Cutting Area Shielding: Belt Standard/Chain Shielding Optional
Warranty (cutter/gearbox): 1 Year/3 Years

Model: RC2048
Product Description: Standard-Duty 48″ Single-Spindle Cutter
Tractor PTO Range (hp): 15-50
Hitch Category / Type: Category 1 / Clevis
Cutting Width (in.): 48
Transport Width (in.): 55
Maximum Overall Length (in.): 85
Deck Length (in.): 60.6
Cutting Height Range (in.): 1-9
Cutting Capacity (in.): 2
Gearbox (hp): 65
Gearbox Output Shaft Diameter (in.): 1.57
Blade Tip Speed (fpm): 13000
Side Frame Thickness (in.): 0.14
Deck Side Depth (in.): 10.5
Approximate Weight (lb.): 620
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Oval Stump Jumper
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Safety-Shielded Driveline: Category 3
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Beams
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Replaceable
Cutting Area Shielding: Standard Chain Shielding

Model: RC2060
Product Description: Standard-Duty 60″ Single-Spindle Cutter
Tractor PTO Range (hp): 25-50
Hitch Category / Type: Category 1 / Clevis
Cutting Width (in.): 60
Transport Width (in.): 67
Maximum Overall Length (in.): 97
Deck Length (in.): 72.6
Cutting Height Range (in.): 1-9
Cutting Capacity (in.): 2
Gearbox (hp): 65
Gearbox Output Shaft Diameter (in.): 1.57
Blade Tip Speed (fpm): 14335
Side Frame Thickness (in.): 0.14
Deck Side Depth (in.): 10.5
Approximate Weight (lb.): 771
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Oval Stump Jumper
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Safety-Shielded Driveline: Category 3
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Beams
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Replaceable
Cutting Area Shielding: Standard Chain Shielding

Model: RC2072
Product Description: Standard-Duty 72″ Single-Spindle Cutter
Tractor PTO Range (hp): 30-65
Hitch Category / Type: Category 1 / Clevis
Cutting Width (in.): 72
Transport Width (in.): 79
Maximum Overall Length (in.): 109
Deck Length (in.): 84.6
Cutting Height Range (in.): 1-9
Cutting Capacity (in.): 2
Gearbox (hp): 75
Gearbox Output Shaft Diameter (in.): 1.57
Blade Tip Speed (fpm): 14963
Side Frame Thickness (in.): 0.14
Deck Side Depth (in.): 10.5
Approximate Weight (lb.): 906
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Oval Stump Jumper
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Safety-Shielded Driveline: Category 3
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Beams
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Replaceable
Cutting Area Shielding: Standard Chain Shielding

Model: RC2084
Product Description: Standard-Duty 84″ Single-Spindle Cutter
Tractor PTO Range (hp): 35-90
Hitch Category / Type: Category 1 & 2 / Clevis
Cutting Width (in.): 84
Transport Width (in.): 91
Maximum Overall Length (in.): 107.3
Deck Length (in.): 97.1
Cutting Height Range (in.): 1-9
Cutting Capacity (in.): 2
Gearbox (hp): 90
Gearbox Output Shaft Diameter (in.): 2
Blade Tip Speed (fpm): 15086
Side Frame Thickness (in.): 0.14
Deck Side Depth (in.): 11.6
Approximate Weight (lb.): 1185
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Oval Stump Jumper
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Safety-Shielded Driveline: Category 4
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Beams
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Replaceable
Cutting Area Shielding: Standard Chain Shielding

Model: RC3060
Product Description: Medium-Duty 60″ Single-Spindle Cutter
Tractor PTO Range (hp): 30-150
Hitch Category / Type: Category 1 & 2 / Clevis
Cutting Width (in.): 60
Transport Width (in.): 67.3
Maximum Overall Length (in.): 99
Deck Length (in.): 73.1
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 3
Gearbox (hp): 150
Gearbox Output Shaft Diameter (in.): 2
Blade Tip Speed (fpm): 15525
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 12.7
Approximate Weight (lb.): 974
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Diamond Stump Jumper; Optional Round
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Tail Wheel: Single
Safety-Shielded Driveline: Category 4
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Tubes
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Replaceable
Cutting Area Shielding: Standard Chain Shielding
Cutting Deck Thickness: 10 Gauge

Model: RC3072
Product Description: Medium-Duty 72″ Single-Spindle Cutter
Tractor PTO Range (hp): 30-150
Hitch Category / Type: Category 1 & 2 / Clevis
Cutting Width (in.): 72
Transport Width (in.): 79.3
Maximum Overall Length (in.): 111
Deck Length (in.): 85.1
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 3
Gearbox (hp): 150
Gearbox Output Shaft Diameter (in.): 2
Blade Tip Speed (fpm): 15900
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 12.7
Approximate Weight (lb.): 1125
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Diamond Stump Jumper; Optional Round
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Tail Wheel: Dual Optional
Safety-Shielded Driveline: Category 4
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Tubes
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Replaceable
Cutting Area Shielding: Standard Chain Shielding
Cutting Deck Thickness: 10 Gauge

Model: RC3084
Product Description: Medium-Duty 84″ Single-Spindle Cutter
Tractor PTO Range (hp): 30-150
Hitch Category / Type: Category 2 & 3 / Clevis
Cutting Width (in.): 84
Transport Width (in.): 91.3
Maximum Overall Length (in.): 123.5
Deck Length (in.): 98
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 3
Gearbox (hp): 150
Gearbox Output Shaft Diameter (in.): 2
Blade Tip Speed (fpm): 16000
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 12.7
Approximate Weight (lb.): 1336
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Diamond Stump Jumper; Optional Round
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Tail Wheel: Dual Optional
Safety-Shielded Driveline: Category 4
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Tubes
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Replaceable
Cutting Area Shielding:Standard Chain Shielding
Cutting Deck Thickness:10 Gauge

Model: RC4060
Product Description: Heavy-Duty 60″ Single-Spindle Cutter
Tractor PTO Range (hp): 40-210
Hitch Category / Type: Category 1 & 2 / Clevis
Cutting Width (in.): 60
Transport Width (in.): 67.3
Maximum Overall Length (in.): 99
Deck Length (in.): 73.1
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 4
Gearbox (hp): 210
Gearbox Output Shaft Diameter (in.): 3
Blade Tip Speed (fpm): 13575
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 12.7
Approximate Weight (lb.): 1042
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Diamond Stump Jumper; Optional Round
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Tail Wheel: Single
Safety-Shielded Drive line: Category 5
Drive line Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Tubes
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Adjustable, Replaceable
Cutting Area Shielding: Standard Chain Shielding
Cutting Deck Thickness: 7 Gauge

Model: RC4072
Product Description: Heavy-Duty 72″ Single-Spindle Cutter
Tractor PTO Range (hp): 50-210
Hitch Category / Type: Category 1 & 2 / Clevis
Cutting Width (in.): 72
Transport Width (in.): 79.3
Maximum Overall Length (in.): 111
Deck Length (in.): 85.1
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 4
Gearbox (hp): 210
Gearbox Output Shaft Diameter (in.): 3
Blade Tip Speed (fpm): 13950
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 12.7
Approximate Weight (lb.): 1210
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Diamond Stump Jumper; Optional Round
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Tail Wheel: Dual Optional
Safety-Shielded Drive line: Category 5
Drive line Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Tubes
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Adjustable, Replaceable
Cutting Area Shielding: Standard Chain Shielding
Cutting Deck Thickness: 7 Gauge

Model: RC4084
Product Description: Heavy-Duty 84″ Single-Spindle Cutter
Tractor PTO Range (hp): 65-210
Hitch Category / Type: Category 2 & 3 / Clevis
Cutting Width (in.): 84
Transport Width (in.): 91.3
Maximum Overall Length (in.): 123.5
Deck Length (in.): 98
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 4
Gearbox (hp): 210
Gearbox Output Shaft Diameter (in.): 3
Blade Tip Speed (fpm): 14250
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 12.7
Approximate Weight (lb.): 1440
Blade Dimensions (in.): (2) .5 x 4
Blade Carrier: Diamond Stump Jumper; Optional Round
Blade Mount System: Greaseable Quick-Change Pins
Blade Pin Diameter (in.): 1.5
Tail Wheel: Dual Optional
Safety-Shielded Driveline: Category 5
Driveline Protection: Slip-Clutch
Frame & Deck Support: 3 x 3 Full Length Structural Tubes
Tractor PTO Speed (rpm): 540
Quick Hitch Compatible: Yes
Skid-Shoes: Bolt-on, Adjustable, Replaceable
Cutting Area Shielding: Standard Chain Shielding
Cutting Deck Thickness: 7 Gauge

Model: MC2096
Product Description: Standard-Duty 96″ Multi-Spindle Cutter, 540 Rpm
Mount Type: Pull-Type / 3-Point Mounted
Tractor PTO Range (hp) (Pull-Type/Mounted): 35 -100 / 45 – 100
Hitch Category – Type (Pull-Type/Mounted): Pivoting Clevis / Category 1 or 2 – Clevis
Cutting Width (ft.): 96
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 1.5
Gearbox (hp): 100 Center / 75 Spindle
Blade Tip Speed (fpm): 15200
Deck Side Depth (in.): 10
Deck Thickness: 10 Gauge
Overall Width (in.): 100
Overall Length (in.): 142 / 96
Approximate Weight (lb.) (Pull-Type/Mounted): 1,467 / 1,213
Blade Dimensions (in.): .5 x 4
Wheel Selection: Laminated
Front and Rear Chains: Standard
Optional Dual Wheels: No
Quick Hitch Compatible: Yes
Gearbox Warranty: 6 Years
Shipping Weight (lb.) (Pull-Type/Mounted): 1,421 / 1,238

Model: MC20120
Product Description: Standard-Duty 120″ Multi-Spindle Cutter, 540 Rpm
Mount Type: Pull-Type / 3-Point Mounted
Tractor PTO Range (hp) (Pull-Type/Mounted): 40 -120 / 60 – 120
Hitch Category – Type (Pull-Type/Mounted): Pivoting Clevis / Category 2 or 3 – Clevis
Cutting Width (ft.): 120
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 2
Gearbox (hp): 120 Center / 90 Spindle
Blade Tip Speed (fpm): 16700
Deck Side Depth (in.): 10
Deck Thickness: 10 Gauge
Overall Width (in.): 124
Overall Length (in.): 155 / 110
Approximate Weight (lb.) (Pull-Type/Mounted): 1,213 / 1,576
Blade Dimensions (in.): .5 x 4
Wheel Selection: Laminated
Front and Rear Chains: Standard
Optional Dual Wheels: No
Quick Hitch Compatible: Yes
Gearbox Warranty: 6 Years
Shipping Weight (lb.) (Pull-Type/Mounted): 1,742 / 1,672

Model: FC20144
Product Description: Standard-Duty 144″ Flexwing Cutter
Tractor PTO (rpm): 540
Tractor PTO (hp): 35 minimum
Tractor Hitch: Swivel Clevis
Cutting Width (ft.): 12
Cutting Swatch (in.): 144
Cutting Height Range (in.): 2-12
Cutting Capacity (in.): 1.5
Transport Width (in.): 96
Blade Tip Speed 540 rpm (fpm): 14,300 center / 14,900 wing
Deck Thickness (in.): 12 Gauge, High-Strength Steel
Side Frame Thickness (in.): 0.179
Deck Side Depth (in.): 11
Weight (tongue/total): 750/2,450
Blade Thickness (in.): 0.5
Blade Width (in.): 4
Blade Overlap (in.): 6
Flex Wing: 90∞ Up, 22∞ Down
Tires: New Ag
Suspension: Spring On Center Section
Main Driveline: Category 4
Wing Driveline: Category 3
Cutting Area Shielding: Standard Chain Shielding
Warranty (Cutter/Gearbox): 1 Year/ 6 Year Limited
Front and Rear Chains: Standard
Overall Width x Length (in.): 152 x 168
Deck Type: Smooth, Sloped
Hinges / Hinge Rod Diameter (in.): 1
Vertical Shaft Size (in.): –
Splitter / Wing (hp): 160 / 75
Blade Type: Hi-Lift
Material Flow System: Fully Baffled
Stump Jumper Type: Standard Oval, Welded
Number of Gearcases: 4

Model: FC30180
Product Description: Medium-Duty 180″ Flexwing Cutter
Tractor PTO (rpm): 540 / 1,000
Tractor PTO (hp): 45-200
Tractor Hitch: Swivel Clevis
Cutting Width (ft.): 15
Cutting Swatch (in.): 180
Cutting Height Range (in.): 2-15
Cutting Capacity (in.): 2.5
Transport Width (in.): 96
Blade Tip Speed 540 rpm (fpm): 15,000 / 16,000
Deck Thickness (in.): 0.135
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 13
Weight (tongue/total): 1,200/4,340
Blade Thickness (in.): 0.5
Blade Width (in.): 4
Blade Overlap (in.): 6
Flex Wing: 90∞ Up, 22∞ Down
Tires: 29î Used Aircraft, Foam-filled Used Aircraft, Laminated Tires
Suspension: Spring On Center Deck
Main Driveline: Category 6 CV
Wing Driveline: Category 4
Cutting Area Shielding: Standard Chain Shielding
Warranty (Cutter/Gearbox): -/ 6 Year Limited
Front and Rear Chains: Standard
Overall Width x Length (in.): 189 x 195
Deck Type: Smooth, Sloped
Hinges / Hinge Rod Diameter (in.): 1
Vertical Shaft Size (in.): 2
Splitter / Wing (hp): 210 / 200
Blade Type: Quick-Change Blade Pins
Material Flow System: Fully Baffled Deck
Stump Jumper Type: Standard Round-Welded
Number of Gearcases: 4

Model: FC30240
Product Description: Medium-Duty 240″ Flexwing Cutter
Tractor PTO (rpm): 540 / 1,000
Tractor PTO (hp): 70-200
Tractor Hitch: Clevis
Cutting Width (ft.): 20
Cutting Swatch (in.): 240
Cutting Height Range (in.): 2-15
Cutting Capacity (in.): 2
Transport Width (in.): 123
Blade Tip Speed 540 rpm (fpm): 15,450/ 16,300
Deck Thickness (in.): 0.135
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 13.25
Weight (tongue/total): 2,400/6,510
Blade Thickness (in.): 0.5
Blade Width (in.): 4
Blade Overlap (in.): 6
Flex Wing: 90∞ Up, 22∞ Down
Tires: 29î Used Aircraft
Suspension: Standard Spring Suspension
Main Driveline: Category 6 CV
Wing Driveline: Category 4
Cutting Area Shielding: Standard Chain Shielding
Warranty (Cutter/Gearbox): -/ 6 Year Limited
Front and Rear Chains: Standard
Overall Width x Length (in.): 250 x 198
Deck Type: Smooth, Sloped
Hinges / Hinge Rod Diameter (in.): 1
Vertical Shaft Size (in.): 2
Splitter / Wing (hp): 235 / 120
Blade Type: Quick-Change Blade Pins, Hi-Lift
Material Flow System: Fully Baffled Deck
Stump Jumper Type: Standard Round-Welded
Number of Gearcases: 4

Model: FC40180
Product Description: Heavy-Duty 180″ Flexwing Cutter
Tractor PTO (rpm): 540 / 1,000
Tractor PTO (hp): 55-275
Tractor Hitch: Swivel Clevis
Cutting Width (ft.): 15
Cutting Swatch (in.): 180
Cutting Height Range (in.): 2-15
Cutting Capacity (in.): 4
Transport Width (in.): 96
Blade Tip Speed 540 rpm (fpm): 16,000 / 16,000
Deck Thickness (in.): 0.179
Side Frame Thickness (in.): 0.25
Deck Side Depth (in.): 13
Weight (tongue/total): 1,350/4,600
Blade Thickness (in.): 0.5
Blade Width (in.): 4
Blade Overlap (in.): 6
Flex Wing: 90∞ Up, 22∞ Down
Tires: 29î Used Aircraft, Foam-filled Used Aircraft, Laminated Tires
Suspension: Spring On Center Deck
Main Driveline: Category 6 CV
Wing Driveline: Category 4
Cutting Area Shielding: Standard Chain Shielding
Warranty (Cutter/Gearbox): -/ 6 Year Limited
Front and Rear Chains: Standard
Overall Width x Length (in.): 189 x 195
Deck Type: Smooth, Sloped
Hinges / Hinge Rod Diameter (in.): 1
Vertical Shaft Size (in.): 3
Splitter / Wing (hp): 275 / 225
Blade Type: Quick-Change Blade Pins
Material Flow System: Fully Baffled Deck
Stump Jumper Type: Standard Round-Welded
Number of Gearcases: 4
